12-inch (300mm) 2-way Studio Monitor Loudspeaker

Designed and engineered in JBL’s world-famous acoustic engineering facility in Northridge, California, the 4349 Studio Monitor is a showcase of patented JBL acoustics technologies. This monitor loudspeaker features a 2-way design with patented High-Definition Imaging (HDI™) horn technology, the patented D2415K dual 1.5-inch (38mm) compression driver, and a 12-inch (300mm) cast-frame, Pure-pulp cone woofer for powerful dynamics and incredibly accurate sound reproduction.

Features

• Patented D2415K 1.5-inch (38mm) dual diaphragm compression driver mated to patented High-Definition Imaging (HDI™) geometry horn.
• 12-inch (300mm) pure-pulp cone woofer in bass-reflex design with dual front-firing tuned ports.
• Choice of Walnut or Black furniture-grade satin wood veneers.
• High-frequency and Ultra High-frequency level attenuators.
• Advanced crossover network.
• Dual sets of gold-plated binding posts with shorting straps.
• Recommended JS-150 speaker stands (sold separately).

General Specifications

• Type: 2-way monitor loudspeaker
• Low Frequency Driver: 12″ (300mm) Pure Pulp cone woofer (JW300PG-8)
• High Frequency Driver: D2415K, 1.5-inch (37.9mm) annular ring, Teonex® diaphragm compression driver with advanced HDI™ geometry horn molded in Sonoglass
• Recommended Amplifier Power: 25 – 200 WRMS
• Impedance: 8 Ohm
• Loudspeaker Sensitivity: 91 dB/2.83V/1m
• Frequency Response: 32 Hz – 25 kHz (-6 dB)
• Coverage Angle, -6 dB @ 20kHz: 80 x 70 Degrees (Hor x Vert)
• Coverage Angle, -6 dB @ 10kHz: 100 x 100 Degrees (Hor x Vert)
• Crossover Frequency: 1.5 kHz
• Enclosure Type: V-braced front-ported cabinet
• Grille Feature: Monitor style to match horn mating features, supplied in dark blue (with walnut cabinet) and black (with black cabinet)
• HF Tone Control: -1 dB to +1 dB in 0.5 dB increments from 1.5 kHz to 6 kHz
• UHF Tone Control: -1 dB to +1 dB in 0.5 dB increments from 5 kHz on up
• Input Type: Dual sets of gold-plated binding posts with shorting straps

Dimensions

• Product Weight: 83 lb (37.7 kg)
• Dimensions with grille: 29″ H x 17.5″ W x 12.5″ D (736.6mm x 444.5mm x 317.5mm) Note

Sold as a Pair.
