A versatile, 2-way loudspeaker primarily designed for wall mounting

The AE105² is the latest addition to the all-new 100 Series, and is equally suited to a bookcase or shelf position.

The AE105² utilises a soft dome tweeter with WDT wave guide along with two 130mm paper cone drivers, one acting as a passive radiator for improved bass performance. Optimised for vertical wall mounting with the listening position at or below the tweeter axis, the AE105² can be used to simply enhance the stereo sound from your TV, or as Front L/R, Centre and Surround channel speakers within multi-channel home cinema systems… whilst partnered with the matching AE108² compact sub-woofer.

Finished in a choice of black, white or walnut vinyl veneers, they are supplied with rear mounting plates, template, wall spacers, black and light grey grilles for easy integration within any room décor.

Technical Information

Tweeter
Acoustic Energy’s bespoke 25mm soft dome tweeter was designed in tandem with the 100 Series bass driver to offer optimum integration and tonal matching. Paired with our Wide Dispersion Technology waveguide, the crossover region between drive units is audibly seamless whilst the high-power neodymium motor assembly ensures reliable, distortion-free high-volume playback.

Drivers
The 130mm bass/mid driver used in the 100 Series has been developed with a high power, long excursion motor to provide satisfying volume levels and bass extension from relatively compact enclosures. The doped paper cone enables a higher crossover point for smoother mid-range and seamless crossover with the tweeter, creating extremely high fidelity, detailed and above all musical sound reproduction.

Cabinet
The 100 Series uses thin, 15mm high density (HDF) enclosures with carefully tuned bracing, reducing harmful resonances whilst retaining body and substance from compact, practical cabinets. The rear slot porting* enhances smooth bass extension with minimal room impact, allowing easy placement. The AE109² and AE120² feature inert mass-loading for additional stability and acoustic damping, all models come supplied with slim magnetic grilles.

*The AE108² is a sealed box with no slot port.

General Specifications

• Drive Unit: 130mm paper cones (one passive)
• Tweeter: 25mm fabric dome
• Frequency Range: 55Hz – 26kHz
• Sensitivity: 91dB
• Peak SPL: –
• Power Handling: 120w
• Crossover Frequency: 3kHz
• Impedance: 6ohms
• Design: 2 way
• Grilles: Slim, cloth magnetic fit (black and light grey)
• Dimensions (mm): 450 x 200 x 120 (HxWxD)
• Weight: 4.7kg (each)
• Finishes: Black, Satin White and Walnut vinyl veneer

Sold as a single unit.
